Public sht As Worksheet
Sub Four_Columns()

Set sht = ActiveWorkbook.Sheets("Four_Cols")
sht.Activate
Dim Colcount As Integer
Colcount = sht.Range("A1").CurrentRegion.Columns.Count

Dim RngAddress As String
LastRow = sht.Range("A1").End(xlDown).Row

RngAddress = sht.Range(Cells(1, 1), Cells(LastRow, Colcount)).Address
FormatForm = Format_Userform(Colcount, RngAddress)

End Sub
Sub Eleven_Columns()
Set sht = ActiveWorkbook.Sheets("Eleven_Cols")
sht.Activate
Dim Colcount As Integer
Colcount = sht.Range("A1").CurrentRegion.Columns.Count
Dim RngAddress As String
LastRow = sht.Range("A1").End(xlDown).Row

RngAddress = sht.Range(Cells(1, 1), Cells(LastRow, Colcount)).Address
FormatForm = Format_Userform(Colcount, RngAddress)
End Sub

Sub Single_Column()
Set sht = ActiveWorkbook.Sheets("Single_Col")
Dim Colcount As Integer
Colcount = sht.Range("A1").CurrentRegion.Columns.Count
sht.Activate
Dim RngAddress As String
LastRow = sht.Range("A1").End(xlDown).Row

RngAddress = sht.Range(Cells(1, 1), Cells(LastRow, Colcount)).Address
FormatForm = Format_Userform(Colcount, RngAddress)
End Sub

Sub Two_Columns()
Set sht = ActiveWorkbook.Sheets("Two_Columns")
Dim Colcount As Integer
Colcount = sht.Range("A1").CurrentRegion.Columns.Count
sht.Activate
Dim RngAddress As String
LastRow = sht.Range("A1").End(xlDown).Row

RngAddress = sht.Range(Cells(1, 1), Cells(LastRow, Colcount)).Address
FormatForm = Format_Userform(Colcount, RngAddress)
End Sub

Sub ThreeRows()
Set sht = ActiveWorkbook.Sheets("Three_Rows")
Dim Colcount As Integer
Colcount = sht.Range("A1").CurrentRegion.Columns.Count
sht.Activate
Dim RngAddress As String
LastRow = sht.Range("A1").End(xlDown).Row

RngAddress = sht.Range(Cells(1, 1), Cells(LastRow, Colcount)).Address
FormatForm = Format_Userform(Colcount, RngAddress)
End Sub
Function Format_Userform(Colcount, RngAddress)
'==============================
'Define the Min and Max Measurements of Userform and Listbox
UFMinHeight = 400
UFMaxHeight = 450
UFMinWidth = 400
UFMaxWidth = 700
LBMinWidth = 110
LBMaxWidth = 600
'==============================
Dim UserformWidth As Long
UserformWidth = Colcount * 110


If UserformWidth > UFMaxWidth Then
UserformWidth = UFMaxWidth
End If

If UserformWidth < UFMinWidth Then
UserformWidth = UFMinWidth
End If

'Defined the height of the Userform based on Number of rows in a worksheet
Dim UserformHeight As Long
UserformHeight = sht.Range("A1").CurrentRegion.Rows.Count * 18

'Add additional 200 for command buttons
UserformHeight = UserformHeight + 200

If UserformHeight > UFMaxHeight Then
UserformHeight = UFMaxHeight
End If

If UserformHeight < UFMinHeight Then
UserformHeight = UFMinHeight
End If

'===========Format the Userform================
With UserForm1
.Width = UserformWidth
.Height = UserformHeight
.BackColor = RGB(210, 95, 95)
.BorderColor = RGB(255, 0, 0)
.BorderStyle = fmBorderStyleSingle
.Caption = "Select The Data"
End With
'==========Format the Listbox======================

With UserForm1.ListBox1
.Left = 10
.Top = 15

'From the Userform Height deducted 200 to place the command buttons
ListBoxHeight = UserformHeight - 200
.Height = ListBoxHeight

'Assigned 110 for each column of Listbox
ListboxWidth = 110 * Colcount

'Maintained the Minimum width
If ListboxWidth < 110 Then
ListboxWidth = LBMinWidth
End If

'if Listbox width exceeds Userform width then .. use Listbox max width
If ListboxWidth > UserformWidth Then
ListboxWidth = LBMaxWidth
End If

.Width = ListboxWidth
.ColumnCount = Colcount
.ColumnHeads = False

'Provided the column width as 90
For C = 1 To Colcount
ColWidth = ColWidth & ";" & 90
Next
ColWidth = Right(ColWidth, Len(ColWidth) - 1)
.ColumnWidths = ColWidth
.RowSource = "=" & sht.Name & "!" & RngAddress
.ListStyle = fmListStyleOption
.MultiSelect = fmMultiSelectMulti
.Font.Size = 18
.ForeColor = RGB(0, 0, 0)
.Font.Name = "Estrangelo Edessa"
.BackColor = RGB(250, 240, 205)
.TextAlign = fmTextAlignLeft
End With

'========Formatting CommandButton1=====
With UserForm1.CommandButton1
.BackColor = RGB(140, 0, 0)
.ForeColor = RGB(255, 255, 255)
.Font.Size = 15
.Font.Name = "Estrangelo Edessa"
.Visible = True
'From the userform height deducted Listbox Top + Listbox Height + Commandbutton Height
RemainingSpace = UserformHeight - 15 - ListBoxHeight - 30

'Centered the remaing space to place the command buttons
HalfReaminingSpace = RemainingSpace / 2
.Top = 15 + ListBoxHeight + HalfReaminingSpace
.Left = 25
End With

'=======Formatting CommandButton2==============
With UserForm1.CommandButton2
.BackColor = RGB(140, 0, 0)
.ForeColor = RGB(255, 255, 255)
.Font.Size = 15
.Font.Name = "Estrangelo Edessa"
.Visible = True
.Top = 15 + ListBoxHeight + HalfReaminingSpace
.Left = UserformWidth - 150

End With



'Show Userform
UserForm1.Show
ColWidth = ""

Set sht = Nothing
RngAddress = ""
ActiveWorkbook.Sheets("Buttons").Activate
End Function
